| Brand Name : | ERIC |
| Model Number : | ER-90 |
| Certification : | ISO9000 |
| Payment Terms : | T/T L/C |
| Supply Ability : | 1000meter per day |
| Delivery Time : | 10days |
Materials: Stainless steel, aluminium, aluminum alloy,copper,
phosphor bronze, etc.
Weaving Pattern:weave. Characters: wall decoration bright,
acid-resistance, alkali-resistance, heat-resistance, Tension
strength-resistance.
Uses: wall decorative architectural mesh for example curtains,
screens for dining hall, isolation in hotels, ceiling decoration,
Animal containment and security fencing, etc.
Features:
1.Aesthetic appeal; 2.Versatile; 3. Architecturally inspired;
4.Variety of openings and sizes; 5.Unique design and appearance;
6.Style and functionality
design | open area | cable wire dia. | cable pitch | bar dia. | bar pitch | thickness | wt |
1 | 40% | 1x1.8 mm | 4 mm | 1.5 mm | 5.5 mm | 5.1 mm | 7.74kg/m2 |
2 | 43% | 1x2.5 mm | 6 mm | 2 mm | 8 mm | 5.5 mm | 7.87kg/m2 |
3 | 62% | 2x2.75 mm | 40 mm | 4 mm | 14.5 mm | 9.5 mm | 9.41kg/m2 |
4 | 37.20% | 3x0.5 mm | 3.5 mm | 0.5 mm | 1.4 mm | 1.3 mm | 2.4kg/m2 |
5 | 71% | 3x1.6 mm | 80 mm | 2.5 mm | 10 mm | 5.7 mm | 4.58kg/m2 |
6 | 65% | 3x2 mm | 80 mm | 3 mm | 10 mm | 7 mm | 6.67kg/m2 |
7 | 65.90% | 3x2.75 mm | 110 mm | 4 mm | 14.5 mm | 10 mm | 8.5kg/m2 |
8 | 67% | 3x3 mm | 110 mm | 4 mm | 14.2 mm | 10 mm | 8.6kg/m2 |
9 | 44.30% | 4x0.75 mm | 26.4 mm | 1.5 mm | 3 mm | 3 mm | 5.2kg/m2 |
10 | 62% | 4x1 mm | 36 mm | 2 mm | 6.6 mm | 4 mm | 4.55kg/m2 |
11 | 40% | 4x2 mm | 50 mm | 3 mm | 6 mm | 7mm | 11.2kg/m2 |
12 | 42% | 4x2 mm | 50 mm | 3 mm | 6 mm | 7 mm | 11.8kg/m |
