| Brand Name : | ERIC |
| Model Number : | ER847-1 |
| Certification : | ISO9000 |
| Price : | 10usd per rolls |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 100000rolls per month |
| Delivery Time : | 10days |
1. Material: Low Carbon Steel Wire,Stainless Steel Wire Mesh
2. Diameter: 0.1-4mm
3. Mesh Size: 3/8"-4"
4. Roll Width: 0.5m-2m
5. Surface Treatment: Galvanized or PVC Coated
6. Weaving Types: Positive Twist, Negative Twist, Positive and Negative twist.
7. Feature: Firm structure,flat surface,anti-corrosion,anti-oxidation
8. Classifiction: Electro Galvanized before/after Weaving
Hot Dipped Galvanized before/after Weaving
PVC Coated Before/After Weaving
Stainless Steel Hexagonal Wire Mesh
Our Services
1. After placing orders will be timely feedback to track the progress of related wire mesh production, shipment, delivery and other production conditions.
2. The third-party inspection always gets real and true data from us and we will send hot hexagonal wire mesh photos to client if there is no inspection from the third-party.
3. In accordance with the stipulated time of shipment delivery, guaranteed wire mesh delivery time and supply capacity.
4. Encounter any quality problems can always contact us, we will promptly communicate timely replacement of the goods .
5. Installation, maintenance and repair instructions with full information.
6. 3-10 years warranty depends on different products and using environment.
| Specifications List of Pvc Coated Hexagonal Wire Mesh | |||
| Opening | Wire Diameter | ||
| Inch | mm | Wire gauge (BWG) | mm |
| 1/4" x 1/4" | 6.4 x 6.4 | 22, 23, 24 | 0.7, 0.6, 0.55 |
| 3/8" x 3/8" | 10.6 x 10.6 | 19, 20, 21, 22 | 1, 0.9, 0.8, 0.7 |
| 1/2" x 1/2" | 12.7 x 12.7 | 16, 17, 18, 19, 20, 21, 22, 23 | 1.6, 1.5, 1.25, 1, 0.9, 0.8, 0.7, 0.6 |
| 5/8" x 5/8" | 16 x 16 | 18, 19, 20, 21, | 1.25, 1, 0.9, 0.8 |
| 3/4" x 3/4" | 19.1 x 19.1 | 16, 17, 18, 19, 20, 21 | 1.6, 1.5, 1.25, 1, 0.9, 0.8 |
| 1" x 1/2" | 25.4 x 12.7 | 16, 17, 18, 19, 20, 21 | 1.6, 1.5, 1.25, 1, 0.9, 0.8 |
| 1-1/2" x 1-1/2" | 38 x 38 | 14, 15, 16, 17, 18, 19 | 2.1, 1.8, 1.6, 1.5, 1.25, 1 |
| 1" x 2" | 25.4 x 50.8 | 14, 15, 16 | 2.1, 1.8, 1.6 |
| 2" x 2" | 50.8 x 50.8 | 12, 13, 14, 15, 16 | 2.8, 2.4, 2.1, 1.8, 1.6 |
| 4" x 4" | 101.6 x 101.6 | 12, 13, 14, 15, 16 | 2.8, 2.4, 2.1, 1.8, 1.6 |
| galvanized hexagonal mesh size | Min. Gal.v. | Width | Wire Gauge (Diameter) | ||
| Inch | mm | Tolerance(mm) | G/SQ.M | BWG | |
| 3/8" | 10mm | ±1.0 | 0.7mm - 145 | 2' - 1M | BWG23-27 |
| 1/2" | 13mm | ±1.5 | 0.7mm - 95 | 2' - 2M | BWG21-25 |
| 5/8" | 16mm | ±2.0 | 0.7mm - 70 | 2' - 2M | BWG22-27 |
| 3/4" | 20mm | ±3.0 | 0.7mm - 55 | 2' - 2M | BWG19-25 |
| 1" | 25mm | ±3.0 | 0.9mm - 55 | 1' - 2M | BWG18-25 |
| 1-1/4" | 31mm | ±4.0 | 0.9mm - 40 | 1' - 2M | BWG18-23 |
| 1-1/2" | 40mm | ±5.0 | 1.0mm - 45 | 1' - 2M | BWG18-23 |
| 2" | 50mm | ±6.0 | 1.2mm - 40 | 1' - 2M | BWG18-23 |
| 2-1/2" | 65mm | ±7.0 | 1.0mm - 30 | 1' - 2M | BWG18-21 |
| 3" | ±8.0 | 1.4mm - 30 | 2' - 2M | BWG17-20 | |
| 4" | 100mm | ±8.0 | 1.6mm - 30 | 2' - 2M | BWG16-19 |
Hexagonal wire mesh:
Type: galvanized hexagonal wire
mesh , PVC hexagonal wire mesh
Mesh size:1/8'',1,4'',3/8'',1/2'',5/8'',1'',1-1/2'',2''
Wire diameter:0.5-2mm
Width:0.9-2m
Length:30m, 45m
Packing:packed by water-proof paper
Hexagonal Wire Mesh Specification:
1. Material: Low Carbon Steel Wire,Stainless Steel Wire Mesh
2. Diameter: 0.1-4mm
3. Mesh Size: 3/8"-4"
4. Roll Width: 0.5m-2m
5. Surface Treatment: Galvanized or PVC Coated wire mesh
6. Weaving Types: Positive Twist, Negative Twist, Positive and Negative twist.
7. Feature: Firm structure,flat surface,anti-corrosion,anti-oxidation
8. Classifiction: Electro Galvanized before/after Weaving
Hot Dipped Galvanized before/after Weaving
PVC Coated Before/After Weaving
Stainless Steel Hexagonal Wire Mesh
